Oak Plywood

Decorative oak faced birch plywood is available from stock (Commercial Joinery Grade Crown Oak A/A), This is used extensively in the manufacture of joinery & shopfitting furniture. Oak faced lightweight poplar plywood and oak faced gaboon / okoume marine plywood can be produced to special production order.

Oak-throughout plywood can be used in a variety of different ways and is suitable for many applications. It is commonly requested for its hard-wearing surface layer veneer (e.g. for flooring applications), or due to its high strength & rigidity (e.g. musical instruments). It is also regularly used in the manufacture of decorative furniture, where the core is to be seen, or even accentuated.

This wood is also available in the form of: European Oak Triply 3-Layer Panels and decorative oak veneered panels & doors

Winwood Products is a oak plywood supplier offering the configurations / options listed below

• Crown oak faced birch plywood held in stock
  (Commercial Joinery Grade both sides A/A)
• Stock thickness: 13mm, 19mm & 25mm
• Stock size: 2440x1220mm
• Stock items supplied in less than full pallets if required
• 1.5mm-60mm available to special order (others by arrangement)
• Standard panel size 2440x1220mm, 3050x1220mm & 3050x1525mm
• Oak faced lightweight poplar or birch plywood available up to:
  3660x1220mm, 3050x1220/1525mm, 2500x2070mm
• Can be supplied raw or precoated with lacquer, oil or special finishes

This product is supplied with Commercial Joinery or Premier Architectural Grade sliced oak veneers bonded on a high quality plywood core in the form of oak faced birch plywood, oak faced lightweight poplar plywood, or oak faced gaboon / okoume lightweight marine plywood.

These face veneers are normally 0.6mm before sanding, but faces of 1.4mm or 2.4mm oak veneer can also be used for decorative edge finish and/or bonded using D4 glue where panels may be exposed to higher moisture content.

Sometimes customers ask for oak veneers to be bonded onto a core of our Oak Triply Three-Layer Panels in order to have a bookmatched veneer face on a core that allows deep machining, e.g. v-grooves to be carved into the surface without exposing a different core.

• Stock item:
  • 2440x1220mm Crown Oak Faced Birch Plywood
• Max size:
  • 3700x1830mm
• Stock thickness:
  • 13mm, 19mm, 25mm
    (others to special production)
• Stock Grade:
  • Commercial Joinery A/A

Crown Oak Faced Plywood - Commercial Joinery Class A

• Class A
  • Sliced oak veneers
  • Bookmatched as standard, or otherwise jointed as requested
  • Can be balance matched and / or sequenced to special order
  • No open defects allowed
• Class B
  • A balancer of the same species
  • As Class A plus any non-open defects that preclude it being used as a face, e.g.
  • Colour & grain variance
  • Mismatched veneers

• This item is not currently available - see Oak Triply Three-Layer Panels for nearest stock alternative
• Supplied to special manufacture in full pallet quantity
• Standard thickness 10mm up to 50mm
• Standard panel size 2500x1500mm
• Calibrated to 80 grit as standard
• Can be supplied raw or coated with various coatings such as clear lacquer or oil

Oak throughout plywood is supplied with closed core, i.e. all open defects are removed from the core.

Oak faced plywood will rely upon the plywood used for its core, e.g. birch plywood or lightweight poplar plywood

• Thickness
  • 1.5-60mm - thicker plywood by arrangement
• Standard sizes
  • Sliced oak faced plywood: 2440x1220mm, 3050x1220mm
  • Rotary oak throughout plywood: 2500x1500mm
• Special sizes
  • Sliced oak faced plywood up to maximum 3660x1220mm , 1525mm or 2500x2070mm
  • Oak throughout plywood up to maximum 2500x1500mm
• Tolerances
  • As per EN 315 (other tolerances by arrangement)
• Face grades
  • Oak Faced Plywood
    Premier Architectural: Two sides or one side / balancer to reverse
    Commercial Joinery: A/A, A/B, A/Balancer
    Merchant Grade: A/A, A/B, A/Balancer (full packs to special order)
  • Oak Throughout Plywood
    EN 635-2 Class II/II
    EN 635-2 Class II/III
